型号 Model | 2510 | 2512 | 3012 | 3015 | |||
Detector Width | 250 mm | 250 mm | 300 mm | 300 mm | |||
Detector Height | 100 mm | 120 mm | 120 mm | 150 mm | |||
Effective Detecting Size | W200*H70 mm | W200*H90 mm | W250*H90 mm | W250*H120 mm | |||
Sensitivity with air test | Fe: 0.5 mm Non Fe: 0.7mm SUS 304: 1.0 mm | Fe: 0.5 mm Non Fe: 0.7mm SUS 304: 1.0 mm | Fe: 0.5 mm Non Fe: 0.7mm SUS 304: 1.0 mm | Fe: 0.5 mm Non Fe: 0.7mm SUS 304: 1.0 mm | |||
Parameter setting | By intelligent product learn | ||||||
Belt Width | 180 mm | 180 mm | 230 mm | 230 mm | |||
Conveyor Length | 1200 mm | 1500 mm | 1200 mm | 1500 mm | |||
Max. Weight on Belt | 5kg | 5kg | 10kg | 10kg | |||
Belt Height | 800±50 or Custom | ||||||
Rejection Option | Air Jet, Pusher, Flipper, Flap Down, Down Belt | ||||||
