Technical parameter:
|
Name |
Chinese Manufacturer Laboratory Infrared Pulse Induction Metal Detector |
|
Channel Dimensions |
500 (W) × 300 (H) mm |
|
Conveyor speed |
0.22m / s |
|
Conveyor Max Load |
150KG |
|
Resolution diameter |
the 0.0787mm metal line |
|
Penetration |
34mm steel plate |
|
the leak dose |
<0.05μGy, / h |
|
Current |
0.4 ~ 0.5mA (adjustable) |
|
Tube voltage |
140-160 KV (adjustable) |
|
Image processing system |
X-ray sensor L shaped photodiode array detector (energy), 12bitdepth |
|
Operating temperature / humidity |
0 °C ~ 45 °C / 20% ~ 95% (not condensing) |
|
Storage temperature / humidity |
-20 °C ~ 60 °C / 20% ~ 95% (not condensing) |
|
Working voltage |
220VAC (± 10%) of 50 ± 3Hz |
|
Power loss |
1.0KW (max) |
|
Noise level |
<53dB |
Product description:
pulse induction metal detector korea, imfared metal detector Core ray ray source: using the original glass tube, the voltage current is adjustable
Sensors: the Japanese original multimode 0.2 x 1.0 (mm) array CMOS sensor
Processor: all embedded DSP system, high speed processing system
Software: using neural network, genetic algorithm (ga) and other advanced pattern recognition technology.
Automatic identification of specific product identification function of auxiliary or function
Application:
Chinese Manufacturer Laboratory Infrared Pulse Induction Metal Detector Cordyceps sinensis, shoes, toys, handbags, clothing, powdered milk, chocolate, ham, ice cream, tin cans,
Medicine, Chinese caterpillar fungus, PVC and all kinds of hardware accessories, electronic components, etc
Other characteristics:
1. Security film security film on the ISO1600
2. X-ray generator
3. Ray beam direction at the end-illuminated
4. X-ray beam divergence angle of 60 °
5. Cooling / working periods Sealed oil bath with hot / cold 100%
6. Display high-resolution 19-inch LCD Samsung monitor
7. Color image display 24-bit true color display
8. Super Image Enhancement clearer image details
9. High penetration shown to enhance the contrast of the bright area in the image, so as to penetrate the area
more clearly.
10. Low penetration shown to enhance the contrast of dark areas in images so as to penetrate the area more
clearly.
11. Magnifying glass to enlarge the local function
12. Rightening / minus dark increase brightness of the image / decrease the brightness of the dark image
13. Images pull back / pull display 20 images, and the current image can be any image processing Image
restoration image is restored to its original state
14. Storage of images in real time save any image can be any image processing, and continuous work to save
15. Original Japanese Hamamatsu detector, image quality, Omron electrical components. Total mass in a
comprehensive manner.
Optional functions:
Image printing function
Bar code printing function
Smart front line transmission function
